No. Name Spec. Remark
01 Capacity 3T/24h
02 Cooling capacity 17.14kW
03 Evaporating temp. -20℃
04 Condensing temp. 40℃
05 Standard environment temperature 25℃
06 Standard water temperature 20℃
07 Power install 10.64KW
08 Compressor 9.67KW
09 Reduction gear 0.18 KW
10 Water pump 0.09KW
11 Condenser fan 0.68 KW
12 Salt water dosing pump 0.016KW
13 Power supply 380V/50Hz/3P
14 Water pressure 0.1Mpa-0.5Mpa
15 Refrigerant R404a
16 Ice temperature -5℃
17 Flake ice thickness 2.0mm
(1.5mm-2.2mm adjustable)
18 Water consumption 0.125 M3/h
19 Water pipe 1/2’
20 Net weight 600kg
21 Machine size 1700*1200*1200mm without ice bin
1700*1350*2500mm with ice bin
Flake ice, with its exclusive physical character, it is the most popular type ice in commercial and industrial cooling/temperature keeping area. 1, appearance about 10-40mm irregular size, thickness 2mm, very dry, temperature -5ºc. 2, flake ice is small chips, no sharp edges, ...
