Standard ï¼according to IEC61215ï¼UL1703
Purposeï¼use to verification module resistance impact ability , artifical hockey use to simulate hail , and to the constant speed impact component , simulate hail climate against component effect .
Parameterï¼
1ï¼Effective impact areaï¼1200 * 2100mm
2ï¼Standard hail diameterï¼25mm±5%
3ï¼Standard hail massï¼7.53g±5%
4ï¼Hail setting speedï¼23.0m/s±5%
5ï¼Speed measurement accurate ï¼Â±2%
6ï¼Hail mass measurement accurateï¼Â±2%
7ï¼Pneumatic shoot system
8ï¼Main functionï¼
ã8.1ãChinese operate interface,setting impact position ,impact speed , hail reference ,time etc reference.
ã8.2ãtwo dimension stepping driving system , the interface can setting the displacement
ã8.3ãcan programme control automatic being multipoint impact test
ã8.4ãthe hail shoot speed through compression airâs pressure adjust
8.5ãlight spot fixed point collimation function ,convenience to ensure impact point position
