GD-32A Variable Wavelength Visible Spectrophotometer

• Model GD-23A Visible Spectrophotometer is designed for the purpose of education and general analysis in low cost.
• It can use Φ10-Φ16mm tube or rectangular cuvette in sample department, high reliable and operate easily.
• It can be used for environmental protection,education etc , qualitative analysis & quantitative analysis can be done.

II.Features

• The instrument has variable wavelength and four scales: transmittance absorbency concentration and factor.
• Using universal test tubes or curette to make measure directly.
• The instrument is micro computerized and easy in operation.
• The 12nm spectral slit width provides the sensitivity required for almost any application.
• Tne solid-state silicon detector covers entire wavelength range, eliminating the need to change detectors between different analyses.
• It is easy to replace the unit of instrument specially the Unit of the Pre-adjusted light source, and make it convenient to maintain.
• Free adjusting for filter exchange.
• atiable for 1-5 cm optical path rectangular cells.

III.Specifications

• Wavelength Range: 340-950nm
• Wavelength Accuracy: ±2.5nm
• Wavelength Repeatability: ≤nm
• Spectral Slit width: 12nm
• Photometry Accuracy:0.5%τ(cell) 0.2%τ(tube)
• Photometry Repeatability: 0.3%τ
• Voltage Requirements:220V±10% or 110V±10%
• Photometry Range:0.0~199.9%(T) -0.3~2.999 A 1~9999 F 0~9999 C
• Interface: RS232

IV.Overall dimension & weight:

• Shipping package dimension: 450-420-280mm
• Gross weight: 9Kg
• Net weight: 6.5Kg

V.Standard configuration:

• ain instrument 1
• Power cable 1
• 0mm glass cell 4
• 0mm cell holder 1
• use (2A) 2

VI.Optional accessories:

• re-adjusted Tungsten-halogen lamp
• 0mm cell holder
• oftware
• S232 signal cable
• erial printer
• Any printer (for software)
