Ti-6Al-4V (Grade 5) is classed as an alpha-beta alloy that is most widely used of high strength titanium alloys. The alloy combines its good mechanical strength and low density with excellent
corrosion resistance. This material is used in areas such as Aero-engine components, Airframe components, Marine equipment, Offshore oil and gas equipment, Power generation industry, Autosport
components and Medical equipment.
A major feature of Ti-6Al-4V is it’s fully heat treatable in sections up to one inch and used up to approximately 400°C (750°F).
Subcategory: Alpha/Beta Titanium Alloy; Metal; Nonferrous Metal; Titanium Alloy
Key Words: Ti-6-4; UNS R56400; ASTM Grade 5 titanium; UNS R56401 (ELI); Ti6Al4V, biomaterials, biomedical implants, biocompatibility.
Component | Wt. % |
Al | 6 |
Fe | Max 0.25 |
O | Max 0.2 |
Ti | 90 |
V | 4 |
Material Notes:
Information provided by Allvac and the references. Annealing Temperature 700-785. Alpha-Beta Alloy.
Applications: Blades, discs, rings, airframes, fasteners, components. Vessels, cases, hubs, forgings. Biomedical implants.
Biocompatibility: Excellent, especially when direct contact with tissue or bone is required. Ti-6Al-4V's poor shear strength makes it undesirable for bone screws or plates. It also has poor surface wear properties and tends to seize when in sliding contact with itself and other metals. Surface treatments such as nitriding and oxidizing can improve the surface wear properties.
Mechanical Properties | |||
Hardness, Brinell | 334 | 334 | Estimated from Rockwell C. |
Hardness, Knoop | 363 | 363 | Estimated from Rockwell C. |
Hardness, Rockwell C | 36 | 36 | |
Hardness, Vickers | 349 | 349 | Estimated from Rockwell C. |
Tensile Strength, Ultimate | 950 MPa | 138000 psi | |
Tensile Strength, Yield | 880 MPa | 128000 psi | |
Elongation at Break | 14 % | 14 % | |
Reduction of Area | 36 % | 36 % | |
Modulus of Elasticity | 113.8 GPa | 16500 ksi | |
Compressive Yield Strength | 970 MPa | 141000 psi | |
Notched Tensile Strength | 1450 MPa | 210000 psi | Kt (stress concentration factor) = 6.7 |
Ultimate Bearing Strength | 1860 MPa | 270000 psi | e/D = 2 |
Bearing Yield Strength | 1480 MPa | 215000 psi | e/D = 2 |
Poisson's Ratio | 0.342 | 0.342 | |
Charpy Impact | 17 J | 12.5 ft-lb | V-notch |
Fatigue Strength | 240 MPa | 34800 psi | at 1E+7 cycles. Kt (stress concentration factor) = 3.3 |
Fatigue Strength | 510 MPa | 74000 psi | Unnotched 10,000,000 Cycles |
Fracture Toughness | 75 MPa-m | 68.3 ksi-in | |
Shear Modulus | 44 GPa | 6380 ksi | |
Shear Strength | 550 MPa | 79800 psi | Ultimate shear strength |
Chemical Compatibility
Titanium forms a very tenacious surface oxide layer, which is an outstanding corrosion inhibitor. The human body and bodily fluids have no effect on titanium. Titanium is also compatible with
bone growth and is the most biocompatible of all metals.
Electrical Properties
The typical electrical properties of Ti-6Al-4V at ambient temperatures are:
Electrical resistivity 1028.6 ohms-cmil/ft (171 microhm-cm)
Electrical conductivity 1.01% (%IACS)
Advantages of Ti-6Al-4V
• Biocompatible
• Low Density
• High Melting Point
