Acid Resistance Conveyor Belt
Product Quick Detail
- Minimum Order
- 100
- Place Of Origin
- China (Mainland)
- Packaging
- According to customer requirements
- Delivery
- 10 Days
Specifications
Technical requirements: implement HG/T3782-2005 standard
This kind of product is suitable for the acid and alkali contact condition.Eg:producing the phosphoric fertilizer,abstracts salt from sea water. The covering rubber is the mixture of rubber and
plastic and filled with acid resistant and alkali resistant inter materials. Which is much better than LDR acid and alkali resistant conveyor belt. The frame Material is polyester,is more reliable
and more acid and alkali resistant than the cotton Canvas core belt. Generally it is made into endless type.
Cover Physical Properties:
| Item | Tensile strength | Elongation at break (%) | Abrasion value (mm³) | Hardness(A) +10-5 |
| Before aging properties | ≥14.0 | ≥400 | ≤250 | 60 |
| After aging properties | ≥12.0 | ≥340 | --- | 65 |
| Note: when the cover thickness is 0.8`1.6mm, the test sample thickness will be the max thickness.At this present, tensile strength and elongation are allowed to under 15% in the list. |
Cover acid-proof alkaline:
| Classify | Soak solution | Concentration |
Steeping condition temperature X time |
Before and after soaking performance rate | |
| Saturation inflation rate | Change rate of strength | ||||
| A1 | HCl | 18% | 50℃ X 96H | under +10% | within -10% |
| A2 | H₂SO₄ | 50% | 50℃ X 96H | under +10% | within -10% |
| A3 | NaOH | 48% | 50℃ X 96H | under +10% | within -10% |
