Glove Box |
Dimensions: 1200mm(L) x 750mm(W) x 900mm(H) .
Case Material: Stainless Steel 304 with 3mm thickness.Removable Front Window Panel |
Chamber Condition | Water concentration: <1 ppm (20°C, 1 atm) Oxygen concentration: <1 ppm (20 °C, 1 atm) |
Air-lock
Antechamber |
One Main antechamberDimensions: 360mm(Dia.) x 600mm(L)
One Mini-Chamber Dimensions (for tools): 150 mm(Dia.) x 300mm(L) |
Lighting | fluorescent lamp (in front of box) |
Control system |
Siemens PLC control system with 6" touch screen display
H2O: 0 - 1000 ppm with an accuracy of 0.1 ppm; O2: 0 - 1000 ppm with an accuracy of 0.1 ppm Pressure: -2500 to 2500 Pa with an accuracy of 1 Pa |
Gas Purification System | Automated Regeneration Process Automated water and oxygen removal Purification |
Purging System | Automatic Purging System allows easy operating and reduce gas consumption |
Glove | One pair; size9 3/4" butyl glove is included for immediate use |
Glove Ports | 2ports (materials:Aluminum alloy); size:220mm(Dia.) |
Height of support | 950mm |
KF40 port | 9 sets |
Tray | 2 layers |
Filter system | 2sets,Inlet and Outlet filter can eliminate particle size > 0.3 μm |
Containment | 1.2m3 |
Welding method | outward flange |
Gas Purification System Model | GP20 |
Application | Remove O2& H2O |
Column | Single column |
Purification capacity | 3M3 |
Filling material | 10kg/column (Copper Catalyst & Molecular Sieve) |
Removal capacity | H2O: 1000g; O2: 30L |
Regeneration gas capacity | 3000L |
Regeneration gas | 5-10%H2&95-90% N2 or Ar |
Cooling system | Water cooled 3-5L/min |
Vacuum pump |
Britain EDWARDS RV-12 pump is included for faster vacuum and removing moisture Vacuum rate: 12m3 /hr |
Leak rate | <0.01Vol% / hr (Depending on oxygen concentration inside the glove box) |
Working Voltage | 220V AC 50/60Hz,10A,Single Phase |
BNC | DN40 |
Shipping Dimension | 86" x 45" x 91" (6.8M3) |
Shipping Weight | 650 kg (1400 lbs) |
Warranty | One Year limited warranty with lifetime support Rusting and damage due to improper storage condition or maintenance is not covered by warranty |
Option |
Custom design model To customers specification Digital, integrally fitted, range: % or PPM Digital, integrally fitted, range: % or PPM Edwards (RV5 recommended) To customers specification Powder coated mild steel (stainless steel option) including fixed feet or castors ...
