Laser type | GaAlAs diode laser |
Model | MER10/MER15 |
Wavelength | 980nm/940nm/810nm |
Output power | 3W/7W/10W/15W |
Operation mode | CW / Pulse |
Pulse duration | 25μs - 9s |
Frequency | 0.1Hz - 20KHz |
Transmission system | 200μm-1000μm fiber with SMA905 connector |
Aiming beam | 635nm,2mW |
Control system | 7 inch HD True Color Display/ Smart Systems |
Power supply | 16.8VCD,4A, 50/60 Hz |
Dimensions | 220(W)*150(L)*135(H) mm |
Weight | 2.65Kg |
