1.Specifications
Size:T:0.7-40mm W:<2.5m L:<6m
Grade:Zr702/704/705, Zr-2,Zr-4
Standard:ASTM B551 /F67/F136
Color: Silvery gray
Size: Thickness: 0.7- 40mm
Width: < 2500mm
Length: 100-6000mm
Supply condition: Cold rolled, Hot rolled, Extruded
2.Element composition:
Grade | Element composition (%) < | ||||||||
Zr+Hf | Hf | Fe+Cr | Sn | H | N | C | Nb | O | |
R60702 | 99.2 | 4.5 | 0.20 | -- | 0.005 | 0.025 | 0.05 | -- | 0.16 |
R60703 | 98 | 4.5 | -- | -- | --0.005 | 0.025 | -- | -- | -- |
R60704 | 97.5 | 4.5 | 0.20~0.40 | 1.0~2.0 | 0.005 | 0.025 | 0.05 | -- | 0.18 |
R60705 | 95.5 | 4.5 | 0.2 | -- | 0.005 | 0.025 | 0.05 | 2.0~3.0 | 0.18 |
R60706 | 95.5 | 4.5 | 0.2 | -- | 0.005 | 0.025 | 0.05 | 2.0~3.0 | 0.18 |
1.Standards:ASTM B551/B551M-07 2.Grades:R60702/R60704/R60705 3.Finishes Designate: not descaled, descaled, descaled and pickled, as-ground 4.Applications: Zirconium Strips, Sheets and Plates are widedly used as chemical columns,vessels and reactors,heat exchangers,Porous ...
ASTM B550 zr 702 zirconium plate target used for sputtering coating ASTM B550 zr 702 zirconium plate target used for sputtering coatingzirconium plate suppliers and zirconium plate manufacturers info Zr 702 Zirconium Round Plate Target for Sputtering Coating Zirconium ...
