8 " ultrafiltration FRP membrane housing as membrane filtration element is used to purify sea waters, laboratory water, hospital water, pharmaceutical water, electronic grade water, domestic and commercial water, general industrial water and so on. This 8 inch ultrafiltration pressure vessel adopts advanced technology and high precision determination of machine manufacturing. And it can be used for a long time for critical and demanding applications, such as reverse osmosis, high filtration and ultrafiltration. In addition, with advantages of low maintenance, anti-aging and anti-oxidation properties, 8 " ultrafiltration FRP pressure vessel is applicable in industrial waste water treatment, brackish water desalination, health care, chemical, medical, power system, food and beverage industry, metallurgical industry and many other areas.
Attention:
Your special requirements can always be met.
Please correct operation in accordance with the instructions.
Above values are only for reference, and cannot be used for construction unless it is confirmed.
Parts form is for reference only, the specific form is based on parts drawings shall prevail.
Specifications are subject to change without notice for further improvement.
Main technical characteristics:
Available working pressure: 150 psi.
Operating temperature: -7°C - 49°C.
Standard test pressure: 1.5 times design pressure.
ASME test pressure: 1.1 times design pressure.
Operation PH range: PH 3-11 water.
Cleaning PH range: 2-12. (less than 30 minutes)
Internal maximum working pressure of water outlet: 125 psi.
Optional feed/concentrate port size:
End port: 1.5 inches.
Side port: 1.5 inches, 2 inches, 2.5 inches, 3 inches, 4 inches.
Applicable standard membranes: Hydranautics, DOW, Filmtec, Desal, Koch, CSM, TORAY and a variety of standard membrane elements.
