pyrometallurgical, standard Copper cathode producing line

Copper cathode producing line
The raw material of cathode copper producing line is mixed purple copper or coarse copper, it will be made into anode copper plate by smelting of pyrogenic refining process. After foaming and washing the anode plate, then put into electrolyte flume for electrolyzing refining process. After seven days, it will be copper cathode plate. The quality standard is GB/T467-1997 of China (CU-CATH-2).
1. The process flow diagram as following:

2. Main component of producing line

2.1 Smelting part of pyrogenic process:
2.1.1 Reverberatory furnace
2.1.2 Disk pouring machine of 14 dies
2.1.3 Lifting system for plate
2.1.4 Air compressor
2.1.5 Anode die of casting iron
2.1.6 Manual feeding machine
2.1.7 Cooling water system
2.1.8 Electric appliance, pipe, material
2.1.9 Combustion system
2.1.10 Baler of copper scrap

2.2 Electrolytic refining part:
2.2.1 Silicon rectifier
2.2.2 Electrical system
2.2.3 Seed plate
2.2.4 Copper cooking flume
2.2.5 Seed plate flume
2.2.6 Washing flume
2.2.7 High position flume
2.2.8 Anode mud flume
2.2.9 Heating device of titanium
2.2.10 Embosser
2.2.11 Fastener and tools
2.2.12 Sheet shears
2.2.13 Nail ear machine
2.2.14 Lift frame of anode, preparation stand
2.2.15 Lift frame of cathode, preparation stand
2.2.16 Grinding machine
2.2.17 Centrifugal machine
2.2.18 Inner lining of electrolyte flume
2.2.19 Tools and clamp of stainless steel
2.2.20 Insulation brick/ plate
2.2.21 Acid proof pump
2.2.22 Acid proof valve and pipe etc
2.2.23 The others
