Trailed Orchard Sprayer

All kinds of farming machines at:http://farming-machine.com/Trailed Orchard Sprayer Introduction
As one of the agricultural pesticide spraying machines, this trailed orchard sprayer is driven by a tractor, and it is a kind of air-assisted spraying machine, mainly used for fruit trees pesticide spraying.
Trailed Orchard Sprayer Features
1.Double-wheel design, easy movement and high stability.
2.Employ imported nozzle, good atomization effect, uniform droplets, high penetrability; and employ maintenance-free ceramic plunger pump.
3.Air-assisted spraying by the equipped fans, flipping the fruit tree leaves and sprinkling pesticide onto the both sides of the leaves, good spraying effect; sending the pesticide to inside of the crown.
4.It completes spraying from bottom to top and the leaves back gets the spraying first, which leads good foliage dressing, because the experiment shows that the leaves back has better absorption than the leaves front.
5.Adjustable spraying amount and droplets, suitable for various pesticides and foliage fertilizer.
6.1.5m wheel-span, available for most orchard plants.
7.Convenient and single-person operation; both one-side and double-side spraying are doable.
8.It should be used with a tractor.
9.High efficiency, saving water, pesticide and labor cost.
Tips: We also supply another kind of sprayer used with a tractor, thesuspension-type sprayerTrailed Orchard Sprayer Technical Data

Model	3WZ-Q60A	3WZ-Q70A	3WZ-Q80A
Tractor HP	≧35HP	≧45HP	≧55HP
Spraying radius	>9m	>12m	>15m
Spraying width	>18m	>24m	>30m
Pesticide pump	grease-free ceramic plunger pump	grease-free ceramic plunger pump	grease-free ceramic plunger pump
Spraying flux	20-50L/min	35-70L/min	35-70L/min
Pesticide box	800L, stainless steel, backwater stirring	800L, stainless steel, backwater stirring	800L, stainless steel, backwater stirring
Spraying fan	600mm aluminum alloy fan	700mm aluminum alloy fan	800mm aluminum alloy fan
Nozzle	18 imported nozzles with adjustable angle	24 imported nozzles with adjustable angle	28 imported nozzles with adjustable angle
Spraying effect	270° spraying, available for partial spraying	270° spraying, available for partial spraying	270° spraying, available for partial spraying
Tyre	wide tyres	wide tyres	wide tyres
Drive shaft	8 keys	8 keys	8 keys
Size	2470*1250*1450mm	2470*1250*1450mm
