Ring Chain Bucket Elevator

Product description

Belt Bucket Elevator for the lower uphill lift, the machine automatically transported upward continuous operation after the supply of materials into the hopper by shaking table.

SIZE of the belt bucket elevator enclosed :

1.The model of belt bucket elevator have TD500,TD630,D160,D250,D350,D450,and so on,except for the data in the table,if you need,you can contact us at any time.
2.The usage of the bucket elevator
Shallow bucket used to convey the material which is moist, easy caking, thrown hard,such as wet material, wet coal etc.
Deep bucket used to convey the material which is dry,loose, easily thrown,such as cCement, coal, gravel etc.
belt bucket elevator has Z type ,L type and C type according to customer's actual needs .

Model	LD100	LD130	LD160	LD250	LD315	LD400	LD500	LD600
Speed:m/s	0.4-1.4	0.4-1.4	0.4-1.4	0.4-1.4	0.4-1.4	0.4-1.4	0.4-1.4	0.4-1.4
Conveying Capacity:cub m/h	<3	<4	<20	<38	<42	<68	<96	<148
Hoisting Height:m	<12	<12	<12	<12	<12	<12	<12	<12
