Engine
|
|
Engine Type
|
4-stroke; SOHC, 4 valves
|
|
Displacement
|
686cc
|
|
Bore x Stroke
|
102.0mm x 84.0mm
|
|
Engine Cooling
|
Liquid-cooled w/fan
|
|
Fuel System
|
Yamaha Fuel Injection (YFI), 44mm
|
|
Starting System
|
Electric
|
|
Chassis
|
|
Front Suspension
|
Independent double wishbone and threaded 5-way preload adjustment
|
|
Front Travel
|
9.1 in.
|
|
Front Brake Type
|
Dual ventilated hydraulic disc, twin piston
|
|
Front Tires
|
AT21 x 7-10
|
|
Rear Travel
|
10.1 in.
|
|
Rear Suspension
|
Cast aluminum swing arm w/rebound and threaded preload adjustment
|
|
Rear Brake Type
|
Ventilated hydraulic disc, twin piston
|
|
Rear Tires
|
AT20 x 10-9
|
|
Dimensions/Capacities
|
|
Dry Weight
|
Curb Weight: 422 lb.
|
|
Fuel Capacity
|
2.9 gal.
|
|
Ground Clearance
|
4.4 in.
|
|
Machine Dimensions (LxWxH)
|
72.6 x 45.5 x 43.9 in.
|
|
Wheelbase
|
50.4 in.
|
|
Drive Train
|
|
Drive Train
|
2WD; sealed O-ring chain, eccentric adjustment
|
|
Final Drive
|
Chain
|
|
Transmission
|
5-speed w/reverse; wet multiplate clutch
|
|
General
|
|
Lighting
|
Dual 30W Krypton multireflector headlights & 3.9/0.5W LED brakelight
|
|
Colors
|
Blaze Orange/White
|
