Welcome to buy CNC plasma cutting machine from Buluoer,which is one of the best cnc cutting machine manufacturers and suppliers in China.

Video of CNC plasma cutting machine:

Working principle of CNC plasma cutting machine :

CNC plasma cutting machine is a new type of thermal cutting equipment.It works based on oxygen + acetylene or propane compressed gas as working gas.High temperature and high flame (or plasma arc) as a heat source ,melt the part of the cutted metal .And while blow the fused metal with a high-speed air stream, forming a narrow slit.The device is not only fast cutting speed, cutting slits narrow, smooth incision, small heat-affected zone, low degree of deformation of the workpiece, simple operation, but also has significant energy, material effects.

Plasma cutting mode of CNC cutting machine:

For stainless steel, aluminum, copper, cast iron, steel and other metal materials cutting.

Performance of CNC plasma cutting machine:

1.Gantry frame structure, system rigidity and high driving accuracy.

2.Bilateral drive, smooth operation.

3.Plasma dual-use CNC cutting system, easy to operate.

4.Automatic acadRcam graphical programming software, simple nesting.

Parameter of CNC plasma cutting machine:

Project	BYC-3000	BYC-4000	BYC-5000	BYC-6000	BYC-8000
gauge（mm）	3000	4000	5000	6000	8000
Effective cutting width（mm）	2500	3500	4500	5500	7500
Machine width（mm）	3500	4500	5500	6500	8500
Number of standard cutting torch（set）	1	2	2	2	2
Track length（m）	4、6、8、10、12……Track: 2 m / section, can select optional track length
Cutting torch travel（mm）	200
Cutting thickness	Flame cutting：5 - 200 mm plasma cutting ：1 - 50 mm (according to the power)
Cutting speed	Flame cutting ：0 - 1000 mm/min plasma cutting：0 - 5000 mm/min
Air-way speed	0 - 6000 mm/min
power	AC220 V/ 380 V 50HZ
Machine drive motor power	800 W/ 2500W
Cutting mode	Flame cutting：Oxygen + acetylene, propane plasma：Compressed air, oxygen, nitrogen, etc.
Drive mode	Bilateral drive
system	Shanghai Jiaotong system or Beijing Si Date
Running accuracy	±0.2mm/m
