Model | LRHS-108-RY | LRHS-270-RY | LRHS-412-RY | LRHS-663-RY | LRHS-816-RY | LRHS-1080-RY |
Test volume | 108 L | 270 L | 412 L | 663 L | 816 L | 1080 L |
Internal dimension | 450x600x400 | 600x900x500 | 750x1100x500 | 850x1300x600 | 850x1600x600 | 900x2000x600 |
Overall dimension | 700x1200x1100 | 870x1400x1150 | 1030x1680x1260 | 1160x2000x1390 | 1190x2260x1450 | 1220x2530x1410 |
Test temperature | 35℃~50℃ | |||||
Test methods | Neutral salt spray test (NSS), Acetic acid accelerated salt spray test (AASS), Copper accelerated acetic acid salt spray test (CASS) | |||||
Test duration | 1~9999 hours/minutes/seconds | |||||
Fog spray methods | Continuous and intermittent | |||||
Salt fog fall-out rate | 1~2ml / 80cm2*h | |||||
Saturator Temperature | RT~65℃ | |||||
Sample holder rods | 6 | 6 | 8 | 10 | 12 | 12 |
V-shaped sample holder | 4 | 6 | 6 | 8 | 8 | 10 |
Sample placing methods | Horizontal, vertical or 15°~30°tilting placing | |||||
Atomizer towers | One | Two | ||||
Control pane | Key-press panel or programmable touch-screen panel | |||||
Working environment | 5℃~30℃,relative humidity ≤85% | |||||
Optional parts | Auto-refill solution tank, water filtration component, additional atomizer, sample rod, v-shaped holder, test salt |
Corrosion tests are carried out to check the resistance of a material or a coating to the corrosion process which is triggered naturally with the reaction (chemical or electrochemical) to the aggression of oxidizing agents such as, for example, atmospheric oxygen, moisture, ...
The working size is 1200*800*500mm. It is according to IEC60068-2-11, IEC 60068-2-52 and other ...
TheSalt Spray Test Model Work Room Size (mm) Exterior Size (mm) Voltage Power (KW) YWX/Q-150 600x450x400 1100x750x930 1Phase/220V 2 YWX/Q-250 900x600x500 1500x900x1150 1Phase/220V 2.5 YWX/Q-750 1100x750x500 1700x1050x1150 1Phase/220V 3.5 YWX/Q-010 1200x800x500 1800x1100x1200 ...
