Top quality Chinese DIN 3015 hydraulic pipe clamps

Hydraulic pipe clamps according to DIN 3015 standards:

Younglee manufacturers hydraulic pipe clamps as per DIN 3015 standards which reduce vibrations due to its unique construction, and hydraulic pipe clamp is the most economic and safety solution for easy and quick pipe, tube, hose, and wire /cable installation and fastening in various industrial fields.

Below are the detailed information of Younglee hydraulic pipe clamps:

1. Main Types & Serious as below:

l Standard stauff pipe clamps according to DIN 3015-1

l double pipe clamps / twin pipe clamps according to DIN-3015-3

l Heavy duty pipe clamps according to DIN-3015-2

l Single-hole Small tube clamps

l Single pipe clamps

l Small Double-holes Pipe Clamp

l Steel multi pipe clamps & anti vibration pipe clamps

2. Size range:

Younglee Hydraulic pipe clamps are fit for tube O. D. 6mm ~ 508 mm;

3. Material:

Mounting metal hardware of pipe clamps: Galvanized Carbon steel / stainless steel(304/316)

Clamp Body: Polypropylene(PP) / Polyamide(PA) / Aluminum(AL)

4. Working Temperature:

PP: -30 centi degree up to +90 centi degree in dark green color

PA: -40 centi degree up to +120 centi degree in dark color

Aluminum for application under high temperature up to 300 centi-degree

5. Features:

Hydraulic pipe clamps supplied by Younglee Metal Products Co., Ltd have advantages as below:

- Excellent corrosion, UV, weathering and chemical resistance - even under extreme conditions.

- Strong strength, accurate dimensions, good hardness.

- Hydraulic pipe clamps are with good impact and vibration dampening and providing strength in the direction of the tube axis.

- Hydraulic pipe clamps are with low maintenance cost.

6. Application:

This product is suitable for oil, liquid and gas pipe / tube installation and fastening in the hydraulic system in different areas such as Marine Hydraulics, Industrial Hydraulics, metallurgy, construction machinery, petroleum industry, chemical industry, ship building, power station and so on.
