ME2-CH2O-Ф16 Electrochemical Formaldehyde Sensor
Product Quick Detail
- Place Of Origin
- China
- Minimum Order
- 1
- Brand Name
- Winsen
- Packaging
- N/A
- Delivery
- 15 Days
Specifications
ME2-CH2O-Ф16 Electrochemical Formaldehyde sensor
ME2-CH2O-Ф16 electrochemical sensor detect gas concentration by measuring current based on the electrochemical principle, which utilizes the electrochemical oxidation process of target
gas on the working electrode inside the electrolytic cell, the current produced in electrochemical reaction of the target gas are in direct proportion with its concentration while following
Faraday law, then concentration of the gas could be get by measuring value of current.
Features
* Low consumption
* High precision
* High sensitivity
* Wide linear range
* Good anti-interference ability
* Excellent stability
Application
Detecting CH2O in civilian, industrial area, and environmental protection
Technical Parameter
|
Item |
Parameter |
|
Detection gas |
HCHO |
|
Measurement Range |
0-10 ppm |
|
Max detecting concentration |
50 ppm |
|
Sensitivity |
(0.55±0.25) µA/ppm |
|
Resolution ratio |
0.02ppm |
|
Response time (T90) |
≤60S |
|
Load resistance (recommend) |
100Ω |
|
Repeatability |
＜2﹪ output value |
|
Output Linearity |
linear |
|
Zero drift (-20 ℃ ～40 ℃) |
≤0.2ppm |
|
Humidity Range |
15﹪～90﹪RH |
|
Temperature Range |
-20℃～50℃ |
|
Pressure range |
normal atmosphere ± 10% |
|
Anticipated using life |
2 years (in air) |
