Compulsory Mixer
Product Quick Detail
- Minimum Order
- 1
- Packaging
- N/A
- Delivery
- 15 Days
Specifications
Compulsory Mixer Can Mix the Mixture Effectively
Compulsory mixer works on the principle of mixing arms rotate at a very high speed around the inner axis of the static mixing tank and the drum is static. Mixture is filled through a screen in the
cover of the mixer. The cover can prevent any spillage of material over the sides of the tank. Mixing is done by several arms which ensure that the mixture is wiped off the sides and the bottom of
the mixing tank. The mixture finished is released by turning the movable segment on the bottom of the tank. Forced mixer has stable performance, high efficiency, good water proof performance,
reasonable design, compact structure. It can mix the mixture uniformly in a short time, also can save labor and time. Forced action mixer can mix various concretes and mortars used in highway,
bridge, tunnel, airport, etc.
An orange 500 ml output compulsory mixer is on the black shelf.
CM-1: Compulsory mixer can mix the mixture well in a short time.A white 1000 ml output compulsory mixer is on the black shelf.
CM-2: Compulsory mixer is safe and easy to operate.A yellow 2000 ml output compulsory mixer has blue motors.
CM-3: Compulsory mixer can mix various concretes and mortars.A yellow heavy duty 3000 ml output compulsory mixer has blue motor.
CM-4: Compulsory mixer can be used in highway, bridge, tunnel and dock.
Specification of Compulsory Mixer
Model Volume of the tank (L) Max usable volume (L) Motor output (kW) Voltage (V) Revolution of the mixer (r/min) Max granulation of the material (mm) Weight (kg)
CMS-1 74 37 1.5 230/400 47 10 96
CMS-2 111 69 1.5/2.2 230/400 47 10 131/137
CMS-3 162 102 2.2/3/4 400 47 16 147/177/187
CMS-4 162 102 4.5/3.4 400 62/126 10 188
CMS-5 179 145 2.2 400 47 10 130
CMS-6 233 148 2.2/3/4 400 47 16 172/202/212
CMS-7 250 200 2.2 230/400 580 27 203
CMS-8 330 208 4/5.5 400 47 20 270/390
CMS-9 471 350 4 400 47 20 300
CMS-10 487 246 7.5 400 30/36 32 605
CMS-11 646 400 7.5 400 30/36 32 700
CMS-12 966 450 9.2 400 30/36 32 820
CMS-13 1005 552 11 400 22 32 1160
Specification of Twin Shaft Compulsory Mixer
Model Volume of the tank (L) Max usable volume (L) Capacity (m3/h) Max aggregate size (mm) Stirring blades Stirring motor (kW) Weight (kg)
Speed (r/min) quantity
JS-14 560 350 17.5 40-60 30 15 3500
JS-15 800 500 25 80-60 35 2 × 7 18.5 4000
JS-16 1200 750 37.5 80-60 31 2 × 7 30 5500
JS-17 1500 1000 80-100 18.5 5200
JS-18 1600 1000 60 80-60 19.5 2 × 8 37 8700
JS-19 1750 1250 80-100 22 5500
JS-20 2250 1500 80-100 30 5800
JS-21 2400 1500 90 80-60 23.5 2 × 8 22 11200
JS-22 3000 2000 80-100 37 7500
JS-23 3200 2000 120 80-100 24.5 2 × 8 37 7500
JS-24 3750 2500 80-100 45 8500
JS-25 4500 3000 80-120 55 9200
JS-26 4800 3000 150 80-120 21 2 × 10 55 9200
JS-27 5300 3500 80-120 55 9600
JS-28 5600 3500 180 80-120 21 2 × 10 55 10500
JS-29 6000 4000 80-150 75 12200
JS-30 6400 4000 200 80-120 19 2 × 10 75 12000
JS-31 6750 4500 80-150 75 12500
Feature
Small vibration force, stable performance, high efficiency, stir well, promise debugging, easy to operate, good water proof performance.
Reasonable design, compact structure, low energy consumption, low noise, safe, environment friendly, no leakage problem.
Drum sets have wear resistant cast liner and mixing blades which are durable and easy to replace.
Multi-combined sealing can avoid the cement and slurry contacting the shaft end, extend the service life of the concrete mixer.
Side plates are made of high wear-resistant alloy cast iron.
Perfect mixing of the individual components of the mixture over a short period of time which guarantees a high quality of the final mixture.
The speed of mixing is 4-5 higher compared to the normal drum mixer.
Variability of stirrers enables to mix of various types of mixture.
Mixing arms can be equipped with rubber spatulas to prevent damage, wear and tear.
Rugged construction enables to work in demanding conditions.
Use of enhanced safety features with no-voltage trigger and terminal switch.
Soft starter for fluent running of blades.
Special cap construction to prevent mixture escape.
Fast and easy cleaning the mixer thanks to demountable mixing part.
Additional pair of auxiliary wheels enables transport the mixer in horizontal position.
Long service life, low operational and maintenance costs.
Application
Compulsory mixer can be used to mix dry concrete, plasticity concrete, flowability concrete, light aggregate concrete, semi-rigid concrete and various mortars. It is usually used in highway,
bridge, tunnel, airport, dock, port, city residential construction, water conservancy, various small and medium-sized precast component factories and other industrial and civilian architecture
working department.
- Country: China (Mainland)
- Business Type: Other
- Market:Americas
- Founded Year:1996
- Address:Fuqiang North Road 889, Zaoqiang County, Hengshui City, Hebei Province, China.
- Contact:yun fei
