Assembleon Nozzles
Assembleon MG-Series (Yamaha YG200)
Part Number Description
0.35 / 0.65 for 0603
KGT-M7710-A0 #201 0.6 / 0.8
9498 396 01480 #202 1.0 / 1.7
KGT-M7790-A0 #209 Ø1.2 / Ø0.65
Assembleon Topaz-X(i)II, Opal-XII, Sapphire-XII (Yamaha YV100X, VY100XF)
Part Number Description
PA 2962/47 (5322 360 10493) #71A (0.6/0.8)
PA 2962/48 (5322 360 10494) #72A (1.0/1.7)
PA 2962/45 (9965 000 02777) #73A (Ø4.0/3.0/2.0)
PA 2962/44 (5322 360 10495) #74A (O-ring)
PA 2962/46 (5322 360 10496) #76A, MELF
KV8-M7WK-A00 #79 (Ø1.2/0.65)
PA 2962/38 (5322 360 10484) #71F
PA 2962/39 (5322 360 10485) #72F
PA 2962/40 (5322 360 10486) #73F
SPECIAL Connector Nozzles
Assembleon Topaz, Emerald (Yamaha YV100-ll, YVL-88)
Part Number Description
5322 360 10198 (PA2962/75) #31 (UFO Tip) without Spring
5322 360 10433 #31 (Round Tip) Special type, without Spring
5322 360 10425 (PA2962/78) #31 (X Tip, 1.0/1.2) Spring loaded
5322 360 10199 (PA 2962/71) #32-1 with Reflector
5322 360 10201 (PA 2962/72) #32-2 (Ø4.0/3.0/2.0)
5322 360 10202 (PA 2962/73) #33
5322 360 10203 (PA 2962/74) #34
5322 360 10272 (PA2962/76) #35, Melf
SPECIAL Connector Nozzles
Assembleon Emerald-X(i)II (Yamaha YV 88X, YV 88XF)
Part Number Description
PA 2962/97 61A Ø0.9 / Ø0.5
PA 2962/98 62A Ø1.0 / Ø1.7
5322 360 10476 (PA 2962/93) 63A
5322 360 10497 64A
5322 360 10477 65A
KV7-M71N1-A0X 61F Ø0.6 / Ø0.8
KV7-M71N2-A0X 62F Ø1.0 / Ø1.7
KV7-M71N3-A1X 63F
KV7-M71N4-A0X 64F
KV7-M71N5-A0X 62F
Assembleon Sapphire, Comet (Yamaha YV112)
Part Number Description
5332 360 10335 Type 51 Ø0.9 / Ø0.5
5322 479 60083 Type 52 Ø1.4 / Ø0.8
5322 479 60084 Type 53 Ø3.0 / Ø2.0
5322 360 10289 Type 54 Ø6.0 / Ø4.0
5322 360 10219 Type 55 Ø10.0 / Ø8.0
Yamaha Dispense Nozzles (YV100D, YV86D, YV64D, YM12D)
Part Number Description
KM4-M7113-01X 2D/2S Ø0.6 / Ø0.3 P=0.7
KG3-M7113-40X 2D/2S Ø0.7 / Ø0.4 P=0.8
KM4-M7113-10X 2D/2S Ø0.8 / Ø0.5 P=1.0
K37-M7113-40X 2D/2S Ø0.9 / Ø0.6 P=1.0
K37-M7113-00X 2D/2S Ø1.3 / Ø0.9 P=2.0
K37-M7113-20X 1D/1S Ø0.8 / Ø0.5 P=0.9
KM4-M7113-20X 1D/2S Ø0.6 / Ø0.3 SP=2.2
KM4-M7113-30X 1D/2S Ø0.8 / Ø0.5 SP=2.2
KM4-M7113-40X 1D/2S Ø1.8 / Ø1.4 SP=4.0
KM4-M7113-50X 1D/2S Ø1.8 / Ø1.05 SP=4.0
if you have interested,pls contact us
Thank you
