U14 fixed center extrusion head for wire insulation
Product Quick Detail
- FOB Price
- USD $4,000.00 / Piece
- Place Of Origin
- China (Mainland)
- Minimum Order
- 1
- Packaging
- standard exporting case packing
- Delivery
- 10working days after paid
Specifications
welcome to Kunshan Yishida Mould Machinery Co.,Ltd
specifications:
| Min conductor | Ø0.2mm |
| Max conductor | Ø10mm |
| Max outer diameter | Ø12mm |
| Spiral diameter | Ø60-90mm |
| Power | 1000W |
| Application | Insulating: Small solid and stranded wires Examples of usage: Solid telephone wire, porous film-a porous insulation, tool wire, flat wire, colored and striped insulation etc. |
| Suitable extrusion material | PVC/PE/PA/PBT/LSZH,etc |
| Insulation layer | single layer single layer+one color stripe single layer+2 color stripes |
| Features | Distribution mono-flow: Conical distribution cartridge Easy to clean – no holes or slots – no dead spots Constant and smooth part flow No stresses and shear strains in the melted composition |
1.we are a professional designed&manufacturer of electric wire head mould.
2.we have established in 1998 and has almost 20years experience in this field.
3.We can produce cable diameter range from 0.24mm-200mm
4.We produce hundreds of machine heads,such as free adjustable,adjustable,single-layer,double-layer co-extrusion,three-layer co-extrusion,flat wire,high temperature wire extrusion head.etc.
5.We have introduced several sets of domestic advanced five-axis CNC machining centers and CNC laths and other professional production exquipments.
if you have any problem,contact me freely.
- Country: China (Mainland)
- Business Type: wire extrusion head,extrusion die. extruder accesspry parts.drawing dies
- Market:Asia,Middle East,Europe,Americas
- Founded Year:1998
- Address:No 122,New Yangxi Road,Luyang Town,Kunshan city,Jiangsu Province,China
- Contact:lynn liu
