Panasonic parts KME machine Smt Parts

KME ( ) CM602 (12-Head)

Part Number Description
N610017371AC #110CS ( 0.6/ 0.4) 1005, Ceramic
N610017371AC-Stl #110S ( 0.6/ 0.4) 1005, Steel
N610017372AC #115CS ( 0.9/ 0.65) 1608, Ceramic
N610017372AC-Stl #115S ( 0.9/ 0.65) 1608, Steel
N610017373AC #120CS ( 1.3/ 0.9) 2125, Ceramic
N610017373AC-Stl #120S ( 1.3/ 0.9) 2125, Steel
N610017375AC #130S ( 2.4/ 1.8)
A1FWA #140S ( 4.0/ 1.4) IC, Pad type
N610017370AC #205CS (0.65/0.35) 0603, Ceramic
101YCO-K0210 #210CS (1.1/0.6) 1005, Ceramic
#218CS (0.5 0.6/ 0.38) 1005~1608, Ceramic
#217CS (1.4 2.0/ 0.9) 2012~3216, Ceramic
N610040788AA #230CS (0.7x1.0, X-type) 1005~1608, Ceramic
SPECIAL Connector Nozzles

KME ( ) CM602 (8-Head), CM402, CM202
Part Number Description
A1FQA #110 ( 0.6/ 0.4) 1005, Ceramic
A1FQA-Stl #110 ( 0.6/ 0.4) 1005, Steel
A1FSA #115 ( 0.9/ 0.65) 1608, Ceramic
A1FSA-Stl #115 ( 0.9/ 0.65) 1608, Steel
A1FTA #120 ( 1.3/ 0.9) 2125, Ceramic
A1FTA-Stl #120 ( 1.3/ 0.9) 2125, Steel
A1FUA #130 ( 2.4/ 1.8)
A1FWA #140 ( 4.0/ 1.4) IC, Pad type
KXFX0387A00 #450 ( 6.0/Ø1.5) Pad type
#460 (1.0x6.0)
#470 ( 4.0/ 3.0)
KXFX03DQA00 #205A ( 0.65/ 0.35) 0603, Ceramic
101YCO-K0210 #210 ( 1.1/ 0.6) 1005, Ceramic
#218 (0.5 0.6/ 0.38) 1005~1608, Ceramic
#217 (1.4 2.0/ 0.9) 2012~3216, Ceramic
N610040784AA #230C (0.7x1.0, X-type) 1005~1608, Ceramic
SPECIAL Connector Nozzles

KME ( ) CM402, DT401, CM20F, CM301
Part Number Description
W1ASA #1001 ( 1.3/ 0.9) Ceramic
W1ASA-Stl #1001 ( 1.3/ 0.9) Steel
W1ATA #1002 ( 3.0/ 2.2) Ceramic
W1ATA-Stl #1002 ( 3.0/ 2.2) Steel
W1AYA #1003 ( 4.0/ 3.0)
W1AUA #1004 ( 8.0/ 3.6) Pad type
W1AVA #1005 ( 10.0/ 6.0) Pad type
SPECIAL Connector Nozzles

KME CM88C-M
Part Number Description
0.65 / 0.35 (0603) Ceramic, Square tip
W13VA (1231C1-11115) 0.65 / 0.45 (1005)
W13YA (1231C1-11165) 0.9 / 0.6 (1608)
W13XA (1231C1-11125) 1.3 / 0.9 (2125)
1231C1-11135 1.3 / 0.9 (2125) MELF
W13WA (1231C1-11145) 1.8 / 1.4 (3216)
1.8 / 1.4 (3216) MELF
W13ZA (1231C1-11154) 3.0 / 2.2 (IC/Small)
4.0 / 1.5 (IC/Large) PAD TYPE

KME CM86C-M2
Part Number Description
1222C2-11131 0.65 / 0.45 (1005)
1222C2-11141 0.9 / 0.6 (1608)
1222C2-11150 1.3 / 0.9 (2125)
1222C2-11161 1.3 / 0.9 (2125 MELF)
1222C2-11170 1.8 / 1.4 (3216)

KME CM85C-MGU
Part Number Description
KM85-06404 0.6 / 0.4 (1005)
KM85-09 0.9 / 0.6 (1608)
KM85-13 1.2 / 0.8 (2125)
KM85-13M 1.3 / 0.9 (2125 MELF)
KM85-16 1.6 / 1.1 (3216)

KME CM82C-ME, CM82C-MG
Part Number Description
1281C1-12092 0.6 / 0.4 (1005)
1281C1-12082 0.9 / 0.6 (1608)
1281C1-12072 1.2 / 0.8 (2125)
1281C1-12032 1.2 / 0.8 (MELF)
1281C1-12062 1.6 / 1.2 (3216)

KME Dispense Nozzles

KME BD10S/12S
Part Number Description
SPECIAL 2D/2S 0.6 / 0.3 P=0.7 (1005)
1020 C0 2D/2S 0.7 / 0.4 P=0.8 (1608)
1016 C1 2D/2S 0.8 / 0.5 P=1.0 (2125)
1021 C3 2D/2S 1.0 / 0.7 P=1.2 (3216)

KME BD30S-M
Part Number Description
10HJCOM0000 2D/2S 0.7 / 0.4 P=0.8 (1608)
10HKCOM0000 2D/2S 0.8 / 0.5 P=1.0 (2125)
