*Brief introduction
As a main product of our company, spraying drying set is a kind of centrifugal or pressurized atomizer, which atomizes liquid materials such as solution, suspension, emulsion or paste into tiny
droplet(surface area increased)and dry them into powder product at once(several to dozens of seconds)by contacting hot air.
*Principle of Operation
Air is transferred into hot air by passing through the heater, and goes into the hot air separator on the top of he dryer, then goes into the drying room evenly. At the same time liquid materials
are sent to the centrifugal atomizer on the top of the dryer by the screw pump with stepless speed regulation, and atomized into tiny droplet which will contact hot air, then dried into dry product
within shortest time, with stepless speed regulation, and atomized into tiny droplet which will contact hot air, then dried into dry product within shortest time. The finished product will be
discharged by the whirlwind separator on the bottom of the whirlwind separator on the whirlwind separator on the bottom of the drying tower and waste air is exhausted by fan. The finished product
will be discharged by the whirlwind separator on the bottom of the drying tower and waste air is exhausted by fan.
*Features
A. At fast drying speed, liquid materials after atomization will increase its surface area largely and can be evaporated its moisture 65% to 98% instantly in the hot air flow so as to finish drying
within 5 to 15 seconds. It is especially suitable for drying of heat sensitive materials.
B. Dried products have even granule, good flow ability and solubility, high purity and good quality.
C. Simple and stable operation, easy adjustment and control as well as automation.
D. Simplifying process of production, superior and sanitary operation environment, and flying dust can be avoided during the drying process.
*Scope of application
1. Organic and inorganic chemical raw materials.2. Plastic resin.3. Egg and milk product and foodstuff. 4. Condiment and spicy.5. Extracts of plant and Chinese traditional medicines.6. Western
medicines.7. Porcelain and construction materials.
*Attentions to Order
1. Name of liquid materials, nature, solid content (or moisture content), viscosity, surface tension, PH value.
2. Volumetric weight after drying, allowable residue moisture, granularity, allowed high temperature.
3. Production, total shift hours per day.
4. Available energy resource and volume of steam, power supply capacity, available volume of coal, oil and steam.
5. Control requirement: if inlet and outlet temperature are needed automatically controlled.
6. Requirement of powder collection: if bag collector is needed to install, environmental requirement of tail gas.
