MICROPORE FILTER PLATE
Product Quick Detail
- Place Of Origin
- China(mainland)
- Packaging
- 2pcs each box
- Delivery
- 15 Days
Specifications
Features:
1) Advanced vacuum dewatering machine in the world
2) Compared with traditional disc filtering vacuum machine, it can save 80%
energy
3) Mainly used in the solid/liquid separation in mines
4) Ceramic filtering plate made from porous ceramic compound material
5) The plate can be used repeatedly and has long using life
6) Material: porous ceramic compound material
7) Mainly used in the solid/liquid separation in mines, the plate can be used
repeatedly and has long using life
8) Practice: widely used in many conditions of solid / liquid separation such as
mineral powder dewatering in nonferrous metal, coal industries, etc.
1) Advanced vacuum dewatering machine in the world
2) Compared with traditional disc filtering vacuum machine, it can save 80%
energy
3) Mainly used in the solid/liquid separation in mines
4) Ceramic filtering plate made from porous ceramic compound material
5) The plate can be used repeatedly and has long using life
6) Material: porous ceramic compound material
7) Mainly used in the solid/liquid separation in mines, the plate can be used
repeatedly and has long using life
8) Practice: widely used in many conditions of solid / liquid separation such as
mineral powder dewatering in nonferrous metal, coal industries, etc.
| Permeability | 4000 L / h.m2 (20°Cpure water pressure0.1Mpa) | |
| Air pressure bounch-back test pressure(humid state) | ≥0.4 Mpa | |
| Back flushing pressure | 0.2 Mpa ~ 0.4 Mpa | |
| Ultrasonic united chemical washing pressure | ≤0.2 Mpa | |
| Assembly precision | Depth of parallesism between the assembly ring reference surface and the plate film | 0.10mm |
| Height between the assembly ring referenct surface and the plate film | 8mm±0.1mm | |
| Precision of putting the disks together | Plate face runout | ≤0.25mm |
| The space between each plate | 5mm± 2mm | |
| Pore size | 0.5 ~7.0μm | |
| warranty | 1 year |
