OPC-R1 PM2.5 Particle Sensor
Product Quick Detail
- Brand Name
- Alphasense
- Minimum Order
- 1
- Place Of Origin
- United Kingdom
- Packaging
- N/A
- Delivery
- 15 Days
Specifications
OPC-R1 Particle Sensor Schematic Diagram
• Reports PM1, PM2.5, PM10 plus histograms
• SPI connection for communication and firmware upgrades
• PC software supplied
• Removable fan exit adaptor
• Small size and low power consumption
• Configurable to specific applications
| OPC-R1 Particle Sensor MEASUREMENT | | |
| Particle range | Spherical equivalent size (based on RI of 1.5) | 0.4 to 12.4 |
| Size categorisation | Number of software bins | 16 |
| Sampling interval | Histogram period (seconds) | 1 to 30 |
| Total flow rate | L/min (typical) | 1.6 |
| Max particle count rate | particles/second | 10,000 |
| Max coincidence probability | %concentration at 10 6 particles/L | 0.84 |
| | %concentration at 500 particles/L | 0.24 |
| | | |
| OPC-R1 Particle Sensor POWER | | |
| Measurement mode | mA (typical) | 95 |
| Laser on, fan off | mA (typical) | < 5 |
| Voltage range | VDC | 4.8 to 5.2 |
| Switch-on transient | mW for 1ms | < 5000 |
| | | |
| OPC-R1 Particle Sensor KEY SPECIFICATIONS | | |
| Digital interface | (No data storage) | SPI Mode 1 |
| Laser classification | as enclosed housing | Class 1 |
| Temperature range | °C | -10 to 50 |
| Humidity range | % rh (continuous) | 0 to 95 (non-condensing) |
| Weight | g | < 30 |
