General Specification
1.Main Features
Operationg Syetem | Window 7 |
Monitor | 12.1 inch LED high-resolution 90° rotatable monitor |
Scanning Mode | B, B/B, 4B, B/M, M, 3D Image Reconstruction |
Keyboard | Back-lit Silicone Keyboard (option) |
Cine Loop | Up to1024 frames |
Gain | 0-255dB |
TGC | 8 segment |
Scanning Depth | Up to310 mm |
Dynamic Range | 20-150dB |
Pseudo-color | 40, or customized |
Body Marking | 140 |
Focus | 4 |
Magnification | 0.8-6.0 |
Probe Connector | 2 |
Language | Chinese/English/Spanish |
Matching Printer | Laser/Vedio/Inkjet/Thermal printer |
Peripheral Port | USB, DICOM3.0, RS232, VGA, VCR, PAL-D |
Measurement & Calculation | B-mode: Distance, Perimeter, Area, Volume, Angle, Histogram, Cross Section, Hip Joint Angle M-mode: Heart Rate, Time, Gradient |
Image Processing Technologies | THI, Pre-process, Post-process, Dynamic Range, Contrast, Frame Correlation, Average Line, Edge Enhancement, Black-white Change over, Gray-scale Transformation&Adjustment, Brightness, Gamma Correction |
2. Applications
Abdominal(Liver,Gallbladder,Spleen, Kidney,
Pancreas)
Gynecology(Uterus, Cervix Uterus, Endometrium, Ovary, Ovarian Follicle, Hydatoncus, Enclosed Mass)
Obstetric(AC, BPD, CRL, FL, THD, GS, OFD, HUMERUS, TIDIA, ULNA, HC, TAD, APTD, FTA, AFI, Analytic report of fetus and the growth
curve)
Cardiology(LV, LV Function, Aorta, Mitral, Valve)
Urology(Left Renal Volume, Right Renal
Volume, RUV, Prostate kidney)
Small Parts(Ophthalmology, Thyroid, Jaw and Face)
3.Standard Configuration
Main system unit, 3.5MHz Convex probe, Power adapter, User manual and disc
4. OptionalItems
4 hours backup lithium battery, Biopsy Bracket
5.Probes Selection
3.5 MHz Convex Probe (3.5-14MHz variable frequency )
7.5 MHz Linear Probe (3.5-14MHz variable frequency )
7.5 MHz Transvaginal Probe (3-10MHz variable frequency)
5.0 MHz Micro-Convex Probe (2-6MHz variable frequency)
7.5 MHzRectalProbe(80 elements)
6. Advanced Technologies
PC platform
Full DigitalUltrasonic Kernel
Engine
One Touch Optimizer
Tissue Harmonic Imaging
3D
ImagingReconstruction
DICOM3.0
Packaging & Delivery
Packaging Details: DoubleBox
Package
NetWeight:4.5kg
GrossWeight:8kg
Package Size:460*400*310mm
Delivery Time: 5-10working days
Warranty
Two years for mainunit(One year warranty for probes)
Please let us know your specific request. We would like to recommend you the most suitable model based on your information.
