1.Main Features
Operationg Syetem | Window 7 |
Monitor | 10.4inch LCD monitor |
Scanning Mode | B, B/B, 4B, B/M, M, 3D Image Reconstruction |
Keyboard | Back-lit Silicone Keyboard (option) |
Cine Loop | Up to1024 frames |
Gain | 0-255dB |
TGC | 8 segment |
Scanning Depth | Up to240mm |
Dynamic Range | 20-150dB |
Pseudo-color | 40, or customized |
Body Marking | 140 |
Focus | 4 |
Magnification | 0.8-6.0 |
Probe Connector | 2 |
Language | Chinese/English/Spanish |
Matching Printer | Laser/Vedio/Inkjet/Thermal printer |
Peripheral Port | USB, DICOM3.0, RS232, VGA, VCR, PAL-D |
Measurement & Calculation | B-mode: Distance, Perimeter, Area, Volume, Angle, Histogram, Cross Section, Hip Joint Angle M-mode: Heart Rate, Time, Gradient |
Image Processing Technologies | THI, Pre-process, Post-process, Dynamic Range, Contrast, Frame Correlation, Average Line, Edge Enhancement, Black-white Change over, Gray-scale Transformation&Adjustment, Brightness, Gamma Correction |
2. Applications
Abdominal
Gynecology
Obstetric
Cardiology
Urology
Small Parts
3.Standard Configuration
Main system unit, 3.5MHz Convex probe, Lithium battery, Power adapter, Carrier suitcase, User manual and
disc
4. OptionalItems
Biopsy Bracket
5.Probes Selection
3.5 MHz Convex Probe (3.5-14MHz variable frequency )
7.5 MHz Linear Probe (3.5-14MHz variable frequency )
7.5 MHz Transvaginal Probe (3-10MHz variable frequency)
5.0 MHz Micro-Convex Probe (2-6MHz variable frequency)
7.5 MHzRectalProbe(80 elements)
6. Advanced Technologies
PC platform
Tissue Harmonic Imaging
3D
ImagingReconstruction
DICOM3.0
Packaging & Delivery
Packaging Details: AluminumCase+Box
Package
NetWeight:2.5kg
GrossWeight:7kg
Package Size:370*295*170mm
Delivery Time: 5-10working days
Warranty
Two years for mainunit(One year warranty for probes)
Parametros basicos: Profundidad de la sonda: 16 niveles Frecuencia de la sonda: 5 niveles Ganancia principal: 0-100% 8 TGC: ajustable Enfoque: 4 Almacenamiento de imagen: 4920 imágenes Pseudo color: 0-7 Área de escaneo (ángulo): 3 niveles Realce de bordes: 0-3 Correlación ...
