General Specification
1.Main Features
Operationg Syetem | No |
Monitor | 10.4inchCRTmonitor |
Scanning Mode | B, 2B, 4B, B/M |
Keyboard | Back-lit Silicone Keyboard (option) |
Cine Loop | Up to 256frames |
Gain | 0-100dB |
TGC | 8 segment |
Scanning Depth | Up to240mm |
Dynamic Range | 0-100dB |
Pseudo-color | 8 colors |
Body Marking | 30 |
Focus | 4 |
Magnification | 1.0, 1.2, 1.5, 2.0 |
Probe Connector | 2 |
Language | Chinese/English |
Matching Printer | Laser/Vedio/Inkjet/Thermal printer |
Peripheral Port | USB, VGA, DICOM3.0, RS232,VIDEO OUT |
Measurement & Calculation | Distance, C/A, HR and PW(obstetrics:BPD, CRL, OFD, TTD, FL, HC, AC) measurement |
Image Processing | Dynamic Range,DSC, The line average turnover,Contrast, Edge Enhancement, Gray-scale Transformation&Adjustment, Brightness, Gamma Correction |
2. Applications
Abdominal
Gynecology
Obstetric(BPD, CRL, OFD, TTD, FL, HC, AC)
Cardiology
Urology
3.Standard Configuration
Main system unit, 3.5MHz Convex probe, User manual and disc
4. OptionalItems
Biopsy Bracket, Ultrasonic Stands, USB Flash Disk
5.Probes Selection
3.5 MHz Convex Probe (3.5-14MHz variable frequency )
7.5 MHz Linear Probe (3.5-14MHz variable frequency )
7.5 MHz Transvaginal Probe (3-10MHz variable frequency)
5.0 MHz Micro-Convex Probe (2-6MHz variable frequency)
7.5 MHzRectalProbe(80 elements)
6. Advanced Technologies
User-friendly Interface
Dual Connector Support Various
Probes
Back-lit Keyboard
Packaging & Delivery
Packaging Details:Box
Package
NetWeight:12kg
GrossWeight:18kg
Package Size:500*400*450mm
Delivery Time: 5-10working days
Warranty
Two years for mainunit(One year warranty for probes)
Please let us know your specific request. We would like to recommend you the most suitable model based on your information.
