4W 3KVAC Isolation Wide Input AC/DC Converters TP04AB
Product Quick Detail
- Place Of Origin
- China
- FOB Price
- USD $6.90 / Piece
- Minimum Order
- 10
- Packaging
- tubes
- Delivery
- 15 Days
Specifications
4W 3KVAC Isolation Wide Input AC/DC Converters
The rated output power of TP04AB is 4W with wide input voltage range, for both AC input and DC input application.High reliability, precision, large power density, ultra-small size, no external heat
sink required, stable output voltage and etc, with over current protection, EMI filter circuit, the rectifier filter circuit, 3000V isolation voltage, short circuit, overload, internal thermal
protection, Widely used in industrial control, telecommunications,instrument, data acquisition, signal control and other electronic systems.
Universal input voltage range Both for AC and DC input voltage Wide input voltage: 4:1
Low power consumption,Low No-load consumption High switching frequency , High output density Output over-load,Short circuit protection
Low Ripple &Noise RoHS compliant Operating temperature : -40℃ to 70℃
SELECTION GUIDE
Part Number Input Voltage Output Efficiency (Typ. )
%
Voltage Voltage （VDC) Current（A）
Voltage （VAC) Voltage（VDC)
TP03AB220S03W 85-265 120-370 3.3 0.60 64
TP03AB220S05W 85-265 120-370 5 0.60 68
TP03AB220S09W 85-265 120-370 9 0.33 70
TP03AB220S12W 85-265 120-370 12 0.25 72
TP03AB220S15W 90-264 120-370 15 0.20 76
TP04AB220S03W 90-264 120-370 3.3 0.80 64
TP04AB220S05W 90-264 120-370 5 0.80 68
TP04AB220S09W 90-264 120-370 9 0.44 70
TP04AB220S12W 90-264 120-370 12 0.33 74
TP04AB220S15W 90-264 120-370 15 0.266 76
All specifications typical at TA=25°C, nominal input voltage and rated output current unless otherwise specified.
