6W 4KV Isolation Wide Input AC/DC Converters TP06AC

Minimum Order
1
FOB Price
USD $8.00 / Piece
Place Of Origin
China
Packaging
tubes
Delivery
15 Days
6W 4KV Isolation Wide Input AC/DC Converters

if any inquiry about PCB mountable converters ,welcome check with us.



We could replace: MurataPS, Recom, TRACO,Aimtec

CUI ,Minmax,Meanwell,XP power,etc,.


TOPPOWER is an ISO certified Factory.

TOPPOWER quality: CE ROSH compliant

Our products are widely used in

Power System, Telecom, Instrumentations & Measurement,

Automotive Electronics, Medical,New energy, Military industries,etc.

TOPPOWER is a leading manufacturer of power converters :


0.1W-40W DC/DC converters & 3W-30W AC/DC converters.

The rated output power of TP06AC series is 6W with wide input voltage range, for both AC input and DC input application.

Universal input voltage range Both for AC and DC input voltage Wide input voltage: 4:1

Fixed switching frequency Overheat protection Over current protection

Short circuit protection RoHS compliant Operating temperature :-25℃ to 70℃

Part Number Input Voltage Output Efficiency (Typ. )

%

Rated

Range values Voltage(VDC) Current(A)

(VAC) (VDC)

TP06AC220S05W 85-300 110-370 5 1.2 69

TP06AC220S09W 85-300 110-370 9 0.66 73

TP06AC220S12W 85-300 110-370 12 0.5 75

TP06AC220S15W 85-300 110-370 15 0.4 76

TP06AC220S24W 85-300 110-370 24 0.25 78




All specifications typical at TA=25°C, nominal input voltage and rated output current unless otherwise specified.
