Based on the X-ray digital detection technology of Rayence flat detector in South Korea, Angshi-X-ray digital imaging system realizes the real-time imaging and HD image acquisition of welded joints by combining the control principle. The detected images can be immediately displayed on site. With high detection sensitivity, high resolution, large dynamic range, with the advantages of true and reliable detection images, high efficiency, accurate positioning, flexible movement, convenient disassembly and easy maintenance.
System consists of: X-ray flat panel detector, digital imaging console computer, console software, wireless transmission and control device X-ray generator and other components.
Rayence flat panel detector Features:
This set of system has many advantages such as high sensitivity, lightness, simple operation, high security, high self-protection, humanized details and HD large image display.
Wireless transmission and control device
Workflow Logic Processing of Imaging System Control Commands
Simultaneous control during X-ray imaging and acquisition
Provide 2.4 / 5G dual-band wireless mode of operation, and Gigabit Ethernet interfaces for data and control command transmission.
Digital Imaging Console
Digital dynamic X-ray real-time imaging system control and image processing workbench, the main functions of real-time monitoring, static analysis and system reset four parts. Using advanced architecture, it achieves seamless operation with digital X-ray flat panel detector, high process automation, good real-time performance and powerful image processing.
X-ray generator parameters
New digital controller, touch the button to adjust the voltage, automatic training digital display.
