Ceramic Membrane Filtration System

Ceramic membrane is a porous fine ceramic filter which is sintered from Aluminia Titania or Zirconia under ultra high temperature. Ceramic membrane normally has an asymmetrical structure with porous support active membrane layer. The macro porous support ensures the mechanical resistance while the active layer functions separation ranging from Microfiltration, Ultrafilatration and even Nanofiltration (from 10μm down to 1KD).

Ceramic Membrane always runs at a CROSS FLOW FILTRATION mode. The turbid fluid goes through membrane layer inside the single channel or a multi channel at a high velocity. Driven by pressure, the clean liquid with micro-molecule pass through the membrane layer vertically to permeation, the solid and big molecule is rejected in retentate. The feed fluid is thus clarified,concentrated and purified.

Compared with normal traditional filters like Filter Press, Centrifuge and DE Filter, Ceramic Membrane Filters have many unique advantages:

l Excellent resistance to acid/alkaline and oxidation chemicals

l Solvent stability

l High thermal stability

l Fine separability with narrow pore size distribution

l Excellent mechanical and abrasive resistance

l Extremely long work life

l Easy to be cleaned and sanitized with backflushing
