Working power:AC220V± 10% V 50± 10% HZ.
IP protection class: 42
Relative humidity:≤ 90%
Open, close the gate time:1 second.
Power-on system startup :1 second.
Direction of access: One-way or bi-directional, always locked or free to pass
The number of people: 30-40 persons/min
Durability: 4 million times of use
Classic material: standard 304 stainless steel. Thickness: 1.2-1.5mm
Finish: High quality power coating plus lacquered finish
Channel: 500mm
Function
Electromagnetic locking and photoelectric sensor unlock function makes it open quickly and work reliably for a long time.
security: The arm would be locked until a legal“open” signal received. The tripod would be automatically locked if the passenger did not pass through the channel in a certain amount of time which can be set up. Standard time is 4 seconds. To protect the mechanism, turnstile would not drop the arm if illegal external collision, destruction happens.
The turnstile would drop arm automatically if the power is cut off. This character is designed to meet fire safety requirements or a emergency.
Turnstile can be adjusted via main control board to set card reading with or without memory function, Thus, After a card reading, one person or several persons can pass according to the set-up.
The tripod turnstile is semi-automatic. After reading illegal card or barcode or fingerprint etc, the passenger needs to push the arm by hand until going through the gate and the arm arrives in home position after the passenger exits. Or you can choose to use pure mechanical model: the passengers push the arm by hand until he goes through directly.
Software ware function: counting passenger numbers, remote control, time attendance, produce in & out report, conference control, set when, where, who can get in and out etc
Communication: Dry contact relay with 12 volt or 24 volt pulse. interface with computer to control
Turnstile can be connected by different devices such as card readers, fingerprint machine, barcode machine etc.
We manufacturetripod turnstile, flap turnstile, swing turnstile and other kinds of half height turnstile,our 24 hour service emailis: cherry_shen@yahoo.com, welcome to contact us.
