10W 4KV Isolation Wide Input AC/DC Converters TP10AC220S15W
Product Quick Detail
- Place Of Origin
- China
- FOB Price
- USD $11.00 / Piece
- Minimum Order
- 1
- Packaging
- box
- Delivery
- 15 Days
Specifications
Part Number Input Voltage Output
Rated
Range values VoltageVDC) CurrentA
(VAC) (VDC)
TP10AC220S05W 85-300 110-370 5 2.0
TP10AC220S09W 85-300 110-370 9 1.11
TP10AC220S12W 85-300 110-370 12 0.83
TP10AC220S15W 85-300 110-370 15 0.66
TP10AC220S24W 85-300 110-370 24 0.41
The rated output power of TP10AC series is 10W with wide input voltage range, for both AC input and DC input application. High reliability, precision, large power density, ultra-small size, no
external heat sink required, stable output voltage and etc, with over current protection, EMI filter circuit, the rectifier filter circuit, 4000V isolation voltage, short circuit, overload, internal
thermal protection, Widely used in telecommunications, industrial control, instrument, data acquisition, signal control and other electronic systems.
Universal input voltage range Both for AC and DC input voltage Wide input voltage: 4:1
Fixed switching frequency Overheat protection Over current protection
Short circuit protection RoHS compliant Operating temperature :-40 to 80
