1. Application
The cable is used in electric transmission and distribution system operating at AC rated voltage up to and including 1.8/3 KV
2. Operating Characteristic
1) The rated voltage U0/U of cable is 0.6/1KV.
2) The long time allowable working temperature of conductor is 70 °C FOR cable with PVC insulation, 90 °C for cable with XlPE insulation.
3) The cable laying temperature is not less than 0°C, and the allowable bending radius of a cable is not less 20 times than cable overall diameter for single core unarmored cable, 15 times of that for single core armored, 12 times of that for 3 cores armored cable.
3. Executive Standard
JB/T12706.1-2008, GB/T19666-2005
AL Core | Description | Application |
VLV | Cu(Al)Core PVC Insulated PVC Sheathed Power Cable | For laying indoors, in ducts and tunnels, but unable to bear pulling force and pressure |
