1. Application:
This series is widely used for the mining industries, hotels, museums, gymnasiums, sport venues, and etc for pipeline pressure, air supply, exhaust and ventilation in the high building.
2. Working condition:
The temperature of the transport gas should be in the range from -20 to 50°C,dust content should less than 100mg/m3
3. Technical Data:
Model No. |
Power
(kW) |
Rotation
(RPM) |
Air Volume
(m3/h) |
Total Pressure (Pa) |
Noise
dB(A) |
3.0F | 0.25 | 1400 | 864-2592 | 179-125 | ≤64 |
3.5S | 0.18 | 910 | 908-2725 | 107-75 | ≤59 |
3.5F | 0.37 | 1400 | 1372-4116 | 243-170 | ≤67 |
4.0S | 0.25 | 910 | 1356-4068 | 139-97 | ≤67 |
4.0F | 0.75 | 1400 | 2048-5163 | 318-222 | ≤76 |
4.5S | 0.37 | 910 | 1931-4862 | 177-131 | ≤68 |
4.5F | 1.1 | 1400 | 2916-5832 | 403-308 | ≤77 |
5.0S | 0.75 | 910 | 2648-6676 | 218-152 | ≤71 |
5.0F | 2.2 | 1420 | 4000-10084 | 498-347 | ≤80 |
6.0S | 1.5 | 960 | 4576-11441 | 312-233 | ≤75 |
6.0F | 5.5 | 1450 | 6912-17425 | 717-500 | ≤84 |
7.0S | 3 | 960 | 7266-18168 | 427-318 | ≤77 |
8.0S | 7.5 | 960 | 10846-21697 | 558-427 |
≤81 |
