Engine

Make and model.............................................T12.38-50

Displacement...............................................11.596 liters

Max. power.................................... 380HP @ 2000 rpm

Max. torque.......................... 1650NM@1300-1600 rpm

Emission standard………………………………. Euro V

Clutch

Plate diameter..........................……….............φ430mm

Gearbox

Type..….........................………………..…..... HW19710

No. of speeds............................. 10 forward, 2 reverse

Front axle

Type.…….Rigid stub axle with double T-cross members

Max. load............................................................ 9000Kg

Tandem axle

Type..........……………….…………Pressed axle housing, single reduction with planetary wheel reduction

Ratio..............................................……...…………...4.77

Steering

Type.....................................................................ZF8118

Overall dimension(length×width×height).....………….………….....8845×2500×3450mm

Wheelbase....………………….………......4125+1350mm

Bodydimension(length×width×height)......………………………6000×2300×1500mm HARDOX steel
