Engine

Make and model…………………..………….. WD615.69

Displacement................................................ 9.726 liters

Maximum output………………..…..336 HP@ 2200 rpm ( 247KW @ 2200 rpm )

Max. torque.......................... 1300NM@1300-1600 rpm

emission standard…………………………..EUROII

Clutch

Type..............Single dry plate, compressed air assistant

Plate diameter..........................……….............φ430mm

Gearbox

Type..….........................………………..…..... HW15710

No. of speeds............................. 10 forward, 2 reverse

Front axle

Type.…….Rigid stub axle with double T-cross members

Max. load............................................................ 6500Kg

Tandem axle

Type..........……………….…………Pressed axle housing, single reduction with planetary wheel reduction

Ratio..............................................……...…………..4.42

Max. load.......................................................….13000Kg

Steering

Type.....................................................................ZF8098

Fuel tank capacity…………………………..…..400L

Wheels and tires

Tire……..........……………….………..…..295/80R22.5

Quantity………………………………………………….9

Brakes

Service brake.................Double circuit pneumatic brake

Parking brake.............. Spring-powered air-cut off brake

HOWO CABIN WITH A/C

Electric equipment

Operating voltage………...…..24 V, negative grounded

Overall dimension(length×width×height).....………….…………..10426

Wheelbase....……………………………..4600+1350mm

Performance

Max. driving speed......………….………....102 km/h

Turning circle diameter..……………….….......... 24m

Mass parameter

Kerb mass.……………………………………......11330Kg

Total mass.........……...…………………………. 32000Kg

Body

Waste water tank:

Volume………………………….……………………..6000L

Thickness……………………………………………….5mm

Discharging type……………………….Rear or dumping

Vacuum Pump:

Type………………………………..…………Water-cooling

Flow of air………………………………………. 450m3/h

Clean water tank:

Volume……………………………………………….5500L

Thickness……………………………………………….4mm
