SL450 Rapid Prototyping System
Product Quick Detail
- Own Patent
- China (Mainland)
- Rapid Prototype
- stereolithography
- Packaging
- 1pcs each pallet
- Delivery
- 3 Days
Specifications
LASER SYSTEM
Type: Diode-pumped solid-state laser Nd:YVO4
Wavelength: 354.7nm
Power at vat at 5000 hours: 350mW
Power auto-adjustment: OptionalRECOATING SYSTEM
Process: Intelligent reduced vacuum press recoater
Normal build style: 0.1mm
Quick build style: 0.125mm
Precision build style: 0.075mm
OPTICAL & SCANNING
Beam (diameter@1/e2): 0.10-0.15mm
Focus style: ScanLab
Part drawing speed: Recommended 6.0m/s
Beam jump speed: Recommended 10.0m/s
Reference Build Weight: 60 ~ 100g/hrELEVATOR
Vertical resolution: 0.0005mm
Position repeatability: ±0.01mm
Maximum part weight: 50kg
RESIN VAT
Volume Approx.: 110.0L (120kg)
Maximum build box: 450mm(X)×450mm(Y)×300mm(Z)
Resin heated style: Hot air
SOFTWARE
Operating system: Windows 7, Ethernet, IEEE802.3
Preparation software: Materialise Magics RP (optional)
Build software: ZERO 4.0 build software
CAD interface: 3D design software, STL file format
INSTALLATION CONDITION
Power: 200-240VAC 50/60Hz, single phase, 15Amps
Ambient temperature:20-26ºC
Built-in air condition: Optional
Relative humidity: Less than 40%, non-condensing
Size: 1.48m(W)×0.95m(D)×1.95m(H)
Weight: Approx. 820kg
you can try rapid prototype rapid prototyping to get through more products
- Country: China (Mainland)
- Business Type: service
- Market:Russia,India
- Founded Year:2011
- Address:No.13,Tongan Road West,Suzhou,Jiagsu Province,P.R.China
- Contact:lucy zhu
