Applications of CVD diamond plates:
CVD diamond is used for semi-finishing, finishing, super finishing and continuous cutting of ultra precision cutting tools. In addition, the CVD diamond is also used for other high-tech applications (such as diamond dresser, wire drawing die, electronics,optical window, heat spreader and gem stone industry, etc).
Advantages of CVD diamond plates:
High transmission,Good Thermal stability and chemical stability.. It is the best replacement of natural diamond .
CVD diamond has low surface roughness and good cutting edge compared to PCD tools.
CVD diamond has higher wear resistance than PCD and other diamond materials.
The thermal conductivity of CVD diamond is 50% higher than PCD.
Good hardness and long life exceed HPHT and natural diamond.
The specification of CVD diamond plates :
length * width * thickness (mm) |
1 * 1 * 1 |
2 * 2 * 1 |
3 * 3 * 1 |
4 * 4 * 1 |
5 * 5 * 1 |
6 * 6 * 1 |
7 * 7 * 1 |
8 * 8 * 1 |
9 * 9 * 1 |
10 * 10 * 1 |
11* 11 * 1 |
12 * 12 * 1 |
Description of CVD diamond:
CVD diamond round
| 30*30mm thickness: 0.2*1.5mm | |
CVD diamond dresser bar | Thickness*Width*Length 0.6mm*0.6mm*3-8mm 0.8mm*0.8mm*3-8mm 1mm*1mm*3-8mm 1.5mm*2mm*3-8mm 2mm*2mm*3-8mm | Dressing tools |
CVD diamond Wafers | Diameter: up to 120mm Avaliable polish: single side or double side | |
CVD diamond Heat Spreaders 10*10mm² | Thickness: 0.2*0.8 mm² Avaliable polish: single side or double side | Cooling of High-Power Electronic Devices. e.g: Laser Diodes |
CVD diamond Cubes/Block | Thickness*Width*Length 0.8mm*0.8mm*0.8mm | dressing tools |
CVD diamond Die Blanks | Shape: Hexagon Inscribed circle Dimension*Thickness(mm² ) 1.5*0.7, 1.5*0.8, 2.0*0.8, 2.0*1.0
| Drawing die |
CVD diamond / WC piece | Triangle, Thickness: 1.6mm diamond layer thickness: 0.3mm-0.7mm Angle*Side Length: 90º*4.5mm, 80º*4.5mm, 70º*4.5mm, 35º*4.5mm | Machining non-ferrous,plastics, and composite materials |
