Specification:
Rate output power(kw):155(130kw-180kw choosable)
Max out put power(kw): 160
Rate frequency(Hz): 50 (50/60 adjustable)
Phase: Three phase
Cylinder arrangement: In-line engine
Number of cylinders: 6
Voltage range(v): 230/400(adjustable)
Engine brand: cummins
fuel consumption(L): 35.4
Size(mm):2500*850*1650
Weight(kg):1670
Feature:
Low fuel consumption
High availability and reliability
Outstanding load acceptance
Long maintenance intervals
Control panel:
1.Display water temperature.
2.Display oil pressure
3.Display oil pressure
4.Display battery charging current.
5.Display generating set operating time.
6.Electrical start button.
7.Base fuel tank is included in the price.
Standard Equipment:
1.Equipment conforms to CE and OQS - ISO9001-2000 quality system standards.
2.Unit power,voltage,engine brand and alternator brand can be adjusted.
3.Units were tested under the standard conditions of temperature and atmospheric pressure, each not less than three hours.
4.Fuel consumption parameters based on the original engine parameters and actual test.
5.The KVA units of power units is 0.8 to calculate the power factor.
6.Converter generator is Brushless excitation,the class of insulation is F.
Warranty
The standard warranty period is 1 year or 1500 running hours since the delivery date, depends on whichever comes first.
Packing
All the parts are packed in export wooded cases.
