MV215FHB-N31 BOE 21.5 inch lcd display
Product Quick Detail
- Place Of Origin
- China Mainland
- FOB Price
- USD $50.00 / Piece
- Minimum Order
- 2
- Packaging
- N/A
- Delivery
- 15 Days
Specifications
MV215FHB-N31 BOE 21.5 inch ADS 1080P widescreen tft lcd module with all viewing angle
MV215FHB-N31 is a color active matrix TFT LCD module using amorphous silicon TFT's (Thin Film Transistors) as an active switching devices. This module has a 21.5 inch diagonally measured active area with FHD resolutions (1920 horizontal by 1080 vertical pixel array). Each pixel is divided into RED, GREEN, BLUE dots which are arranged in vertical stripe and this module can display 16.7M colors. The TFT-LCD panel used for this module is adapted for a low reflection and higher color type.
Features:
LVDS Interface with 2 pixel / clock
High-speed response
0.5t Glass
6-bit (Hi-FRC) color depth, display 16. 7M colors
Incorporated edge type back-light (One Light Bar)
High luminance and contrast ratio, low reflection and wide viewing angle
DE (Data Enable) only
RoHS/Halogen Free
ES 7.0 compliant
Gamma Correction
Reverse type
High-speed response
0.5t Glass
6-bit (Hi-FRC) color depth, display 16. 7M colors
Incorporated edge type back-light (One Light Bar)
High luminance and contrast ratio, low reflection and wide viewing angle
DE (Data Enable) only
RoHS/Halogen Free
ES 7.0 compliant
Gamma Correction
Reverse type
Application：
Desktop Type of PC & Workstation Use
Slim-Size Display for Stand-alone Monitor
Display Terminals for Control System
Monitors for Process Controller
Slim-Size Display for Stand-alone Monitor
Display Terminals for Control System
Monitors for Process Controller
General Specification：
| Panel Brand | BOE |
| Panel Size | 21.5 inch |
| Panel Model | MV215FHB-N31 |
| Panel Type | a-Si TFT-LCD , CELL |
| Pixel Format | RGB Vertical Stripe |
| Resolution | 1920(RGB)×1080 , FHD |
| Display Area | 476.064(W)×267.768(H) mm |
| Outline Size | 483.646（W）×278.676（H）×1.32（d）毫米 |
| 挡板开幕 | - |
| 表面 | 防眩，硬涂层（3H） |
| 亮度 | 0坎德拉/平方米 |
| 视角 | 89/89/89/89（典型值）（CR≥10）左/右/上/下 |
| 在最佳浏览 | 对称 |
| 玻璃深 | 0.50 +0.50毫米 |
| 显示颜色 | 16.7M |
| 频率 | 75HZ |
| 重量 | 0.40公斤 |
| 对比度 | 1000：1（典型值）（TM） |
| 显示模式 | ADS，常黑，透射[屏库版权，复制严禁] |
| 响应时间 | 14（典型值）（G到G） |
| 透过率 | 5.6％（典型值）（与偏振器） |
| 灯类型 | 没有B / L |
| 触摸屏 | 没有 |
| 应用 | 桌面显示器 |
| 信号接口 | LVDS（2声道，8位），30个引脚，连接器 |
| 输入电压 | 5.0V（典型值） |
| 环境 | 操作温度：0〜50℃; 存储温度：-20〜60℃下 |
