Automatic Paper Embossing Machine MODEL YW-E -iseef.com
Product Quick Detail
- Minimum Order
- 1
- Place Of Origin
- China
- Packaging
- N/A
- Delivery
- 25-40 Days
Specifications
Product description:
The automatic paper embossing machine with the functions: automatic feeder & auto collecting picker. Full automatic control in processing, adopt frequency governor, automatic hydraulic system and pneumatic blade, it is characterized by controllable speed, double-sheet control, automatic counting, etc. Its average can range from 3000~5000pc/h. It is applied to embossing the sheet surfaces of batches like packing products, playing cards, gift cards, golden and silver card paper, etc.
Optional collector:
-Auto vibrating collector
-Manual collecting table
Main technical parameter:
| Model: | YW-720E | YW-920E | YW-1150E | YW-1300E |
| Max. embossing speed: | 80m/min | 80m/min | 80m/min | 80m/min |
| Max. embossing width: | 680mm | 880mm | 1000mm | 1180mm |
| Paper range: | >160gsm | >160gsm | >160gsm | >160gsm |
| Operation pressure: | 2-10Mpa | 2-10Mpa | 2-10Mpa | 2-10Mpa |
| Main motor pressure: | 14kw | 15kw | 16kw | 18kw |
| Vacuum pressure: | 0.06Mpa | 0.06Mpa | 0.06Mpa | 0.06Mpa |
| Air source pressure: | 0.8-1.0Mpa | 0.8-1.0Mpa | 0.8-1.0Mpa | 0.8-1.0Mpa |
| Overall dimension(L*W*H): | 4800*1500*1800mm | 4800*1700*1800mm | 4800*1800*1800mm | 4800*2000*1800mm |
| Machine weight: | 2800kgs | 3500kgs | 4200kgs | 5000kgs |
- Country: China (Mainland)
- Business Type: Manufacturer,Trading Company
- Market:Africa,Americas,Asia,Emerging Markets,Europe,European Union,G20,Middle East,Oceania
- Founded Year:2007
- Address:2F208, NO.161 SANGUANDIANXIANG,XINHE STREET
- Contact:Mancy Mao
