Application:
Steel cord conveyor belts a re widely used in high strength, long distance and heavy load transportation of materials and they are also used in high strength and shont distance transportation of materials on special occasions.
Feature:
1.High tensile strength:The belts a re suitable for large span, long distance transportation of materials.
2.Small elongation in use:The belts need only a very short take-up stroke distance.
3.Small diameter of drive pulley:The belt body has a layer of longitudinally arranged steel cords as its skeleton,and thus is resistant to flex fatigue.Therefore drive pulley of smaller diameter can be used to make the equipment smaller.
4.High adhesion between rubber and steel cord:The steel cords a re coated with zinc on their surface, and also the rubber used has the property of good adhesion with steel cords.Therefore, the rubber is tightly adhered to the steel cords and is resistant to shock and difficult to drop, so the rubber belts are long in life.
5.Even tension of steel cords:Out of our advanced techniques in manufacturing, the steel cords are very evenly arranged and have the same tension, so the belts are well balanced in running and difficult to run away.
6.Good troughability:As the belt body has no transverse skeleton, it is easy to form a deep trough, so the belts can load more materials and prevent the materials from escaping.
7.Inspection of the skeleton steel cords on the convey or machines to prevent accidents from happening.
Adhesion of steel cord
Strength | ST600 | ST800 | ST1000 | ST1250 | ST1600 | ST2000 | ST2500 | ST3150 | ST4000 | ST4500 | ST5000 | ST5400 | ST6300 |
Adhesion N/mm GB9770-88 | 54 | 60 | 64 | 69 | 74 | 84 | 98 | 108 | 118 | ||||
Adhesion N/mm DIN22131-88 | 60 | 70 | 80 | 95 | 105 | 105 | 130 | 140 | 145 | 150 | 165 | 175 | 180 |
If you need please contact me
