Ventilated Stretch Film

Minimum Order
5
Place Of Origin
China
Size
Customized
Color
Customized
Packaging
Packing in bales or pallets
Delivery
15 Days


Ventilated Stretch Film

MLLDPE air flow ventilated pallet wrap film requires the following three models:

1): 1200 meters X 50 cm x 30 um (machine ),
Technical parameters:
Pre-stretching rate: 230%
Average thickness: 30um +/-3um
Width: 500mm +/-5%
Damage stretch rate: 250% +/-15%
Damage tension: 26kg +/-15%
Number of holes: 13
Weight per meter: 10.11g +/-10%
Net weight per roll: 12.132kg +/-10%
Packing: 40 rolls per pallet (2 layers x 20 rolls), 42 pallets / 40 feet container, a total of 1680 rolls (20.38 tons) / 40 feet high container.

2): 4000 m X42 cm x 9um, net weight per roll: 17.92kg +/-10% (machine )
Technical Parameters:
Pre-stretching rate: 65 %
Average thickness: 9um+/-3um
Width: 420mm+/-5%
Damage elongation: 75% +/-15%
Damage tension: 50kg +/-15%
Number of holes: 13
Weight per meter: 4.48g +/-10%
Packing: 32 rolls / pallet(2 layers x 16 rolls), 42 pallets/ 40 feet container, 1344 rolls(24.08 tons) / 40 feet high container

3): 500 m X 42 cm x 9 um, net weight per roll: 2.24 kg +/- 10% (manual )
Technical Parameters:
Pre-stretching rate: 65 %
Average thickness: 9um+/-3um
Width: 420mm+/-5%
Damage elongation: 75% +/-15%
Damage tension: 50kg +/-15%
Number of holes: 13
Weight per meter: 4.48g +/-10%
6 rolls (13.44kg) / CTN, 24 CTNS / pallet, carton: 57x38x31cm, 144 rolls / pallet, 42 pallets / 40HQ., 6048 rolls (1008 CTNS, 13.55 ton) / 40 HQ

Characterise:

1.Less material use for wrapping a load when compared to the alternative solutions.

2.Eliminates condensation and mold formation.

3.Suitable for light or heavy loads.

4.Requies less films to stabilise the pallets .

5.quicker and easier to apply than corner boards and straps.

6. Low weight ,but high elasticity .
