20x18TU-AH Slurry Pump
Product Quick Detail
- Place Of Origin
- China
- Minimum Order
- 1
- Packaging
- wooden case
- Delivery
- 20 Days
Specifications
Size: 20" x 18"
Capacity: 2520-5400m3/h
Head: 13-57m
Speed: 200-400rpm
NPSHr: 5-10m
Eff.: 85%
Power: Max.1200kw
Handling solids: 140mm
Seal arrangement: Packing seal, Expeller seal, Mechanical seal
20x18TU-AH Slurry Pumpis the world’s most comprehensive centrifugal slurry pumps for use in mining, chemical and industrial applications. The 20x18 slurry pumps are designed for ultra heavy duty applications such as mill discharge, process plant and tailings, high pressure pipelines, as well as other specialty applications.
√ Heavy duty construction with through-bolt design provides ease of maintenance and minimal downtime.
√ Ductile iron fully lined casing provides durability, strength, safety, and long service life.
√ Large diameter, slow turning, high efficiency impellers designed to achieve maximum wear life and low operating costs.
√ Large, open internal passages designed to reduce internal velocities, maximise wear life and lower operating costs.
√ Thick elastomer or alloy bolt-in liners provide superior corrosion resistance plus offer ease of liner change-out and interchangeability to reduce overall maintenance costs and maximise wear life.
√ Minimal shaft/impeller overhang reduces shaft deflection and increases packing life.
√ Cartridge-style bearing assembly allows for maintenance in a clean environment without removal of the pump, resulting in reliable operation and prolonged bearing life.
√ Grease or oil lubrication bearing assembly options offer ease of maintenance and reduced downtime.
√ Optional dry running shaft seal reduces or eliminates flush water requirements
√ Effective expeller prolongs packing life while reducing or eliminating flush water requirement.
√ Interchangeability of seal arrangements – full flush, low flow, centrifugal, or mechanical seals may be fitted to any sized pump.
