Metal mesh sand screen for coarse formation

Metal mesh sand screen is a combination of fixed pore geometry & high strength structural support. It usually consists of a single or multiple layers of diffusion boned (sintered) laminates. It is often used in standalone completions or gravel-packed wells and cased hole.

Sintered metal mesh screen provides broad range of opening ratings from 40 micron to 1000 micron. Screen material is a vital element in sand screen selection and improving well performance. Generally speaking, stainless steel 304, 304L, 316, 316L and other Inconel or Monel special alloy are used.

Product description:
Material: stainless steel 304, 304L, 316, 316L and other Inconel or Monel alloy;
Diameter: 1” to 4”;
Length: 20 feet;
Opening rating: 40 to 100 micron;
Weave pattern: Twill Dutch & Reverse Dutch;
MOQ: 100 pcs.

Features & Advantages:

• Lower pressure drop;
• More flow area;
• High degree of flexibility and high strength;
• Controllable pore size;
• Reusability;
• Light weight.

Applications:

• Unconsolidated formations;
• Horizontal completion;
• Open-hole packed completion;
• Coarse formation.
