XSD-4B inverted biological microscope

Model

XSD-4B

Optical

System

Infinity color corrected optical system

Eyepiece

High eye-point plan eyepiece PL10X/22, field of view: 22mm.

High eye-point plan eyepiece PL10X/22, field of view: 22mm, with reticle.

High eye-point plan eyepiece PL15X/16, field of view: 16mm

Objective

OLIPP2N long working distance

plan positive phase contrast objective 4X、10X、20X、40X

Nosepiece

Revolving quintuple nosepiece（option: quadruple nosepiece）

Viewing Head

45°inclined binocular head, interpupillary distance range: 54-75mm.

45°inclined trinocular head, interpupillary distance range: 54-75mm.

fixed splitting ratio for binocular: trinocular= 80:20.

Stage

Fixed stage size: 250x160mm, slider clips,

extension plate and coaxial moveable stage can be assembled.

Focusing

adjustment

Coaxial focus system with up-limited and tension adjustment.

Coarse range: 9mm, fine range: 0.2mm, fine precision: 0.002mm.

Attachable

moveable

stage

Coaxial focus system, range: 120x78mm, various of holders can be assembled.

Holder

Slides holder（φ54mm and 26.5x76.5mm）

Teraseki holder（φ65mm and 56x81.5mm）

φ35mm Petri dish holder

Condenser

N.A.0.3 Koehler illumination condenser, with phase-adjustable slide plate,

long working distance 72mm. The whole set can be rotated down.

Filter

φ45mm green interference filter, color temperature change filter,

infrared eliminate filter

Illumination

5W warm color LED 12V3.3A external transformer, intensity adjustable.
