L-S3M inverted biological microscope

Product Quick Detail

Minimum Order
1
Packaging
N/A
Delivery
15 Days

Main

parameters

Total

magnification

100X~400X
Mechanical

tube length

Conjugate distance

of objective

Eyepiece Wide-field

plan eyepiece

WF 10X FNФ22mm Ф30mm Parfocal distance 10mm
Trinocular Hinged binocular tube, with an observation angle of 45°, and a pupil distance of 53-75mm
Modulation

Contrast

objective

Magnification N.A W.D(mm) T (mm) Note
10X 0.25 4.3 1.2 For modulation contrast

view, The modulator of

objective should be adapted

with slot in the condenser

20X 0.40 8.0 1.2
40X 0.60 3.5 1.2
Bright field

objective

10X 0.25 4.3 1.2 For bright field view
20X(option) 0.40 8.0 1.2
40X(option) 0.60 3.5 1.2
Phase-contrast objective 10X(option) 0.25 4.3 1.2 For phase contrast view, the

objective phase shutter

should be adapted with the

cirque shutter in the connser

20X(option) 0.40 8.0 1.2
40X(option) 0.60 3.5 1.2
Nosepiece Quintuple
Condenser Working distance 55mm, adapted for turntable type modulation contrast view
Working distance 55mm, adapted for puller type modulation contrast view(option)
Working distance 55mm, with phase-contrast device (option)
Working distance 55mm with aperture diaphragm,adapted for bright field view(option)
Stage Mechanical Stage, moving range 77mm (longitudinal)X134.5mm (transverse),

detachable stage moving device

Focus system Coaxial carse/fine focus with tension adjustable and up stop ,

Minimum division of fine focusing is 2 um

Culture

dish holder

Holder 1 86mm (W)X129.5mm (L), optional with a circular culture dish Ф87.5mm
Holder 2 34mm (W)X77.5mm (L), optional with a circular culture dish Ф68.5mm
Holder 3 57mm (W)X82mm (L)
Light source 6V/30W halogen lamp, adjustable in brightness
