L-S3 inverted biological microscope
Product Quick Detail
- Minimum Order
- 1
- Packaging
- N/A
- Delivery
- 15 Days
Specifications
| Specification | ||
| Eyepiece | Wide field WF10X(field number:22mm) | |
| Centering telescope | ||
|
Infinity and long
working distance plan achromatic objective |
Objective | PLL 10X0.25 Work distance：4.3 mm£¬Cover glass thickness：1.2mm. |
| PLL 20X0.40 Work distance：8.0 mm£¬Cover glass thickness：1.2mm. | ||
| PLL 40X0.65 Work distance：3.5 mm£¬Cover glass thickness:1.2mm. | ||
|
Phase Contrast
Objective |
PLL 10X0.25 PHP2 Work distance：4.3 mm£¬Cover glass thickness：1.2mm. | |
| Eyepiece tube | Inclination angle is 45˚ and interpupillary distance is 53~75mm. | |
| Focus system |
Coaxial coarse/fine focus, with tension adjustable and up stop minimum
division of fine focusing is 2μm. |
|
| Nosepiece | Quintuple nosepiece | |
| Stage | Fixed stage overall size is 227mmX208mm | |
| Glass rotundity stage overall size is Ф118mm | ||
| Mechanical moving device, moving range is 77mm (longitudinal)X114mm (transverse) | ||
| Culture dish holder 1 |
Inside locating slot size: 86mm (W)X129.5mm (L),
optional with a circular culture dish Ф87.5mm |
|
| Culture dish holder 2 |
Inside locating slot size: 34mm (W)X77.5mm (L),
optional with a circular culture dish Ф68.5mm |
|
| Culture dish holder 3 | Inside locating slot size:：57mm (W)X82mm (L) | |
| Condenser system |
Long working distance condenser, working distance: 55mm,
and with turnplate phase contrast unit |
|
| Illumination system | 6V30W halogen, brightness enable control | |
| Filter | Frosted glass and blue , green filter |
