Model | L-I2 |
Eyepiece | Wide field WF10X(20mm) |
Objective | Long working distance plan achromatic PL L 10X/0.25 |
Long working distance plan achromatic PL L 25X/0.40 | |
Long working distance plan achromatic PL L 40X/0.60 | |
Long working distance plan achromatic phase contrast objective
PL L 10X/0.25 PHP2 |
|
Eyepiece tube | Trinocular (Inclination of 30°, 100% image light for photography capable) |
Focus system |
Coaxial coarse/fine focus, with tensional adjustable and up stop
minimum division of fine focusing: 2μm. |
Nosepiece | Quadruple(Ball bearing inner locating) |
Stage |
Double layer mechanical
(Size:224mmX208mm,moving range:112mmX79mm) |
Shelf of
specimen |
Match to install ¦µ68mm or 77mmX29mm culture utensil |
Match to install 82mmX57mm culture utensil | |
Match to install 128mmX85mm 96 holes culture utensil | |
Filter | Blue filter |
Green filter | |
Frosted filter | |
Sliding phase
contrast unit |
Centering telescope |
10X Sliding phase plate | |
Condenser Rack & pinion adjustable, NA=0.4,working distance: 50mm | |
Light source | 6V 30W Halogen lamp with brightness control. |
Place of Origin: Jiangsu, China Brand Name: YANYANG Model Number: XSP-300V Theory: Biological Microscope Drawtube: Binocular Viewing head: Compensation Free Binocular Head Inclined at 45 degree Eyepiece: WF10X, WF16X(optional) Objective: 4X, 40X, 40X(spring), 100X(spring, oil) ...
Quick Details Place of Origin: Jiangsu, China Brand Name: OEM Model Number: XSP-200D Theory: Biological Microscope Drawtube: Monocular Viewing head: Compensation Free Monocular Head Inclined at 45 degree Eyepiece: WF10X, WF16X(optional) Objective: 4X, 40X, 40X(spring), ...
Quick Details Place of Origin: Jiangsu, China Brand Name: OEM Model Number: XSZ-107V Theory: Biological Microscope Drawtube: Binocular Viewing head: Compensation Free Binocular Head Inclined at 45 degree Eyepiece: WF10X, WF16X(optional) Objective: 4X, 40X, 40X(spring), ...
